| Type: | Heat Resistant Steel | Material: | 1.4841, X15CrNiSi25-21, 314 |
|---|---|---|---|
| Product: | Stainless Steel 314, 1.4841 Hot And Cold Rolled Sheet, Plate, Coil And Strip | Surface: | No.1, 2B |
| Specification: | DIN EN 10095 Heat Resisting Steels And Nickel Alloys | Characteristic: | Resistant To Scaling Up To About 1150 °C |
| Highlight: | 1.4841 Stainless Steel Sheet,AISI 314 Stainless Steel Sheet |
||
Heat Resistant Stainless Steel Sheet 1.4841, X15CrNiSi25-21, AISI 314 Plate
DIN EN 10095: 2018 heat resisting steels and nickel alloys,
Austensitic stainless steel EN 1.4841, DIN X15CrNiSi25-21, AISI / SAE 314
for components that need to be scale resistant up to about 1150 °C.
Chemical composition %
| C | Si | Mn | P | S | Cr | Ni | N |
| 0.20 max. | 1.5~2.5 | 2.0 max. | 0.045 max. | 0.015 max. | 24.00~26.00 | 19.00~22.00 | 0.11 max. |
Mechanical properities
|
Tensile strength Rm Mpa |
Proof stress Rp0.2 Mpa |
Elongation after fracture A80 % min. | Hardness |
| 550~750 | 230 min. | 28 | HB 223 max. |
Form of supply
stainless steel 314, 1.4841 hot and cold rolled sheet, plate, coil and strip, bars, rods, wires
